 Post subject: Re: M18 in a mk3 project
PostPosted: Mon Nov 02, 2009 7:40 am
Offline

Joined: Mon Aug 25, 2003 12:00 am
Posts: 3493
Location: Brisbane
Soul -try a search on brake pads theres been plenty of discussion over the years.

_________________


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Mon Nov 02, 2009 11:40 am
Offline
User avatar

Joined: Fri May 28, 2004 12:18 pm
Posts: 1403
Location: NSW
Awesome!! 8)
I can't wait to see how well it goes on the dyno with the Adaptronic when fully tuned.

My ongoing refinement of my Adaptronics tune is seeing better than standard NA fuel economy now and that is with the boost. :lol:

The key to getting a great tune with the Adaptronic or any aftermarket ECU really is to have as short a vacuum line to the MAP sensor as possible. (less delay)

It makes me laugh when I see ECU's with built in MAP sensors now.


Last edited by itsdamo on Mon Nov 02, 2009 11:48 am, edited 1 time in total.

Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Mon Nov 02, 2009 11:42 am
Offline
Moderator
User avatar

Joined: Mon Aug 25, 2003 12:00 am
Posts: 17515
Location: ACT
itsdamo wrote:
It makes me laugh when I see ECU's with built in MAP sensors now.


Why is that?

_________________
Suzuki MightyBoy - Three pots and a snail.


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Mon Nov 02, 2009 11:48 am
Offline
User avatar

Joined: Fri May 28, 2004 12:18 pm
Posts: 1403
Location: NSW
[YLD80Y] wrote:
itsdamo wrote:
It makes me laugh when I see ECU's with built in MAP sensors now.


Why is that?


As I said above to get a really good tune you need as short a vacuum line as possible between map sensor and engine to minimise delay.
When a ECU with built in map sensor is fitted inside the cabin there is usually a long vacuum line run to it. (unless a new hole has been punched in firewall) and the result is a tune that is always poor no matter how hard you try... they usually have to mask the delay issue with more fuel everywhere down low thus economy, driveability and transient throttle response suffers.


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Mon Nov 02, 2009 2:01 pm
Offline
Moderator
User avatar

Joined: Mon Aug 25, 2003 12:00 am
Posts: 17515
Location: ACT
Fair enough. I asked because my MicroTech has a built-in MAP sensor and a 60cm length of hose running to it, with a baffle chamber about half way along. I did have it set up with a 30cm hose and no baffle chamber, but found that the intake was too 'pulsey' to get a decent tune.

So like most things, what works for one motor doesn't work for every motor. ;)

_________________
Suzuki MightyBoy - Three pots and a snail.


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Thu Nov 05, 2009 5:25 am
Offline
User avatar

Joined: Fri May 28, 2004 12:18 pm
Posts: 1403
Location: NSW
[YLD80Y] wrote:
Fair enough. I asked because my MicroTech has a built-in MAP sensor and a 60cm length of hose running to it, with a baffle chamber about half way along. I did have it set up with a 30cm hose and no baffle chamber, but found that the intake was too 'pulsey' to get a decent tune.

So like most things, what works for one motor doesn't work for every motor. ;)


True, the Adaptronic has onboard circuitry to filter the MAP sensor signal so pulsing and such is minimised... thus a short vacuum hose in Adaptronic world is more critical than it may be with other ECU's that don't have the filtering.


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Sun Nov 08, 2009 11:39 pm
Offline
User avatar

Joined: Mon Aug 25, 2003 12:00 am
Posts: 2194
Location: Brisbane, QLD
WOW! Fantastic Dave :) the engine looks even more fitting than the g13b! very tidy conversion. will be very interesting to see performance figures (final dyno figures, 1/4mile time etc)
Keep up the good work! =D>

_________________
gotta luv a suzi! Love the 4-door - 1.5L DOHC


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Fri Nov 27, 2009 12:24 pm
Offline
User avatar

Joined: Fri Jun 11, 2004 10:33 pm
Posts: 127
Location: Corinda, Brisbane, Queensland
How's this one going Dave? =P~

Any more progress? [-o<

Dano :D

_________________
Bean Here, Done This



Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Fri Nov 27, 2009 7:56 pm
Offline

Joined: Mon Aug 25, 2003 12:00 am
Posts: 3493
Location: Brisbane
Well I received my Inovate LC1 wide band sensor so plugged that into the adaptronic and set in self learn mode and went for a six hour drive,the tune is pretty damn good now,but I still need to get on a dyno in order to set up the vvt control,I have a good idea where to start with this but need the dyno to show torque figures.
The rest of the car has been fitted out with a really nice std gti interior and sound system.
Ive been a bit too busy to work on this one but when I get back from the Homebush race meet this will be priority.
The car drives beutifully with the big cc making a real load of tourqe down low ,accelerates very quickly from low revs even though its only running 7psi at this stage.

_________________


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Sat Nov 28, 2009 5:02 pm
Offline
User avatar

Joined: Fri May 28, 2004 12:18 pm
Posts: 1403
Location: NSW
Awesome!
Any hassles getting a 1800cc turbo conversion registered?


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Sat Nov 28, 2009 5:29 pm
Offline

Joined: Mon Aug 25, 2003 12:00 am
Posts: 3493
Location: Brisbane
Certainly no problem in qld ,has already been mod plated for the M18turbo conversion with no questions asked.Also mod plated for the brake upgrade,half cage, at the same time.

_________________


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Sat Nov 28, 2009 5:30 pm
Offline
User avatar

Joined: Fri May 28, 2004 12:18 pm
Posts: 1403
Location: NSW
Wow!
I need to move to Qld. 8)


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Wed Dec 02, 2009 6:38 pm
Offline

Joined: Mon Aug 25, 2003 12:00 am
Posts: 3493
Location: Brisbane
VVT control function now sorted and working well,its pretty amazing how much difference the vvt makes, the suzuki workshop manual says there is up to 60 degrees of travel on the inlet cam timing,at the moment Ive set it up with 35degrees as a starting point.
Took the car for another 2hrs drive today in rapid learn mode with the VVT working and the car runs really good,easily lights up the tyres in the first three gears!! :oops:
will get it back to the dyno next week and do the higher load and rpm stuff then a power run :P

_________________


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Wed Dec 02, 2009 6:44 pm
Offline
Moderator
User avatar

Joined: Mon Aug 25, 2003 12:00 am
Posts: 11061
Location: RedlineGTi HQ
Good news, did Adaptronic come up with a fix?

Keen to see what this puts out.. dyno before the end of the week! :D


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Wed Dec 02, 2009 8:21 pm
Offline

Joined: Mon Aug 25, 2003 12:00 am
Posts: 3493
Location: Brisbane
Adaptronic have been very helpful trying to sort out a electrical interference problem and this was tracked down to the adaptronic ignition coil driver wires getting feedback,they have built a new adaptronic ecu with more noise filtering built in to eliminate this problem.
Unfortunately it wont be dynoed this week,I am off to Homebush race meeting tomorrow until monday arvo, but it will be dynoed early next week.

_________________


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Thu Dec 03, 2009 8:50 am
Offline
User avatar

Joined: Wed Dec 31, 2008 2:40 pm
Posts: 264
Location: Melbourne
loving this project, but I especially love the disguised oil catch can, it's so perfect! haha.


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Sun Dec 06, 2009 11:49 pm
Offline
User avatar

Joined: Mon Oct 16, 2006 10:09 pm
Posts: 1154
Location: Melbourne
The M engine looks to have less width than the g13b.
A very clean and aspiring project.


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Fri Dec 11, 2009 6:39 am
Offline
Moderator
User avatar

Joined: Mon Aug 25, 2003 12:00 am
Posts: 11061
Location: RedlineGTi HQ
The week is running out :lol:


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Fri Dec 11, 2009 7:31 am
Offline

Joined: Mon Aug 25, 2003 12:00 am
Posts: 3493
Location: Brisbane
Should be dynoing today, if not early next week.

_________________


Top
 Profile

 Post subject: Re: M18 in a mk3 project
PostPosted: Fri Dec 11, 2009 4:22 pm
Offline
Moderator
User avatar

Joined: Mon Aug 25, 2003 12:00 am
Posts: 3527
Location: Brisbane
he is a busy man, he was doing more important things yesterday, like racing around lakeside all day :lol:

_________________
A dyno will tell you anything you want, the 1/4 mile will tell you the truth!!!!
12.10@125mph ST, 58.98 sprint track@QR, 61.6 Lakeside, 294HP ATW


Top
